Viton rubber material for gasket sealing chemical resistance
Reference Standard: ASTM standard
Quality Certification: SGS RoHS2.0 REACH
Color: Black/Red/Green/Blue/White
Packing Information: Regular / Up to your choice
Packed with plastic film.
Packed with plastic film and with PP woven bag.
Wooden pallet.
According to the customer request, fixed-length or heavy package.
Get more information:
Email: info@chn-rubber.com
P .H & Wechat: 008615222735180
Viton Rubber Sheets are well known high quality rubber sheets with excellent resistance to hydrocarbons, chemicals, oils and heat. It is used to make viton rubber gasket with good heat resistance, chemical resistance, acid and alkali resistance, and oil resistance. Viton also has excellent compressive strength, especially at high temperatures. Custom viton gaskets are basically used in harsh environments such as petroleum industry, aviation, automobile industry, aerospace industry and so on.
KEY FEATURES
- Viton gasket has good chemical resistance.
- High temperature heat resistance.
- Excellent sealing ability in corrosive environments.
- Viton gasket resists deformation.
- Excellent resistance to UV and ozone.
- Resists liquid penetration under harsh conditions.
- Good flame retardancy.
- viton gaskets chemical resistance are ideal for various chemical industries.
FKM RUBBER SHEET PERFORMANCE & SPECIFICATIONS
| FKM RUBBER SHEET TECHNICAL PARAMETERS | |||||
| Code | Specific Gravity | Hardness (+/-5) | Tensile Strength | Elongation at Break | Colour |
| g/cm³ | Shore A | Mpa | (min） % | --- | |
| STANSDARD | ASTM D397 | ASTM D2240 | ASTM D412 | ASTM D412 | --- |
| ZXZRS20001V | 1.9+/-0.05 | 70 | 7-8 | 300 | Black/Red/White/Green/Blue |
| ZXZRS20001V | 2.0+/-0.05 | 70 | 5-6 | 250 | Black/Red/White/Green/Blue |
| Note: 1MPa =10.2 Kg/cm² 1N/mm =1.02 Kg/cm | |||||
