PRODUCT
1.6g/cm³ EPDM anti-aging outdoor use rubber sheet black
Reference Standard: ASTM standard
Quality Certification: SGS RoHS2.0 REACH
Thickness: 3mm; Thickness over 15mm, available in sheet form
Specification (W/L):
Width: Standard 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: Standard 5mtrs 10mtrs 15mtrs 20mtrs. Available upon request
Color: Black
Packing Information: Regular / Up to your choice
Packed with plastic film.
Packed with plastic film and with PP woven bag.
Wooden pallet.
According to the customer request, fixed-length or heavy package.
Product Supply Form: Roll / Sheet or Plate / Strip
Get more information:
Email: info@chn-rubber.com
P .H & Wechat: 008615222735180
EPDM sheet is also one of the hybrid rubber elastomers, but it achieves a balance of various properties, especially EPDM's weather resistance, which can withstand extreme climate environments. Therefore, EPDM material is an excellent medium for outdoor use. EPDM is not afraid of being exposed to strong sunlight outdoors, which will not affect its service life. The hardness of EPDM can maintain good flexibility in project engineering. This is a non-reinforced (no cloth interleaving fabric) EPDM rubber mat, which has the same effect as the rubber sheet, and is a high-grade, versatile rubber material, also has good flexibility, has Superior tensile strength and elongation breaking point.
As a rubber sheet manufacturer, we can provide you with different sizes and specifications about EPDM solid rubber roll material, EPDM rubber pad is an excellent rubber sheet for outdoor projects, because epdm rubber sheet has excellent anti-aging properties And ozone resistance, able to show excellent performance in extreme weather climates, and soft will not tear, long life. Our thickness can be from 1mm to 100mm, it depends on you. Customized specifications are also available according to specific projects, please contact us for help with your project.
SBR RUBBER SHEET PERFORMANCE & SPECIFICATIONS
| TECHNICAL PARAMETERS | ||||||||
| Code | Specific Gravity | Hardness (+/-5) | Tensile Strength | Elongation at break | Colour | Finish Type | ||
| g/cm³ | Shore A | Mpa | (min） % | |||||
| STANSDARD | ASTM D397 | ASTM D2240 | ASTM D412 | ASTM D412 | --- | --- | ||
| ZXZRS20101S | 1.6+/-0.05 | 70 | 2.5-3 | 180 | Black | Smooth in both sides OR 1/2 With sides cloth OR 1 side With anti-slip texture | ||
| ZXZRS20201S | 1.6+/-0.05 | 70 | 2.5-3 | 180 | Red | |||
| ZXZRS20401S | 1.6+/-0.05 | 70 | 2.5-3 | 180 | Green | |||
| ZXZRS20001S | 1.6+/-0.05 | 70 | 2.5-3 | 180 | Customized production according to demand | |||
| Note: 1MPa =10.2 Kg/cm² 1N/mm =1.02 Kg/cm |
||||||||
| SPECIFICATION | ||||||||
| Item | Thickness | Width | Length | Insertion | Weight | |||
| mm | m | m | Material | Layers | KGS/m² | lb/ft² | ||
| 1 | 1 | Standard width | 5m/10m/15m/20m | Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas | / | 15.36 | 3.15 | |
| 2 | 1.5 | Standard width | 5m/10m/15m/20m | / | 24.96 | 5.11 | ||
| 3 | 1.7 | Standard width | 5m/10m/15m/20m | 1PLY | 28.80 | 5.90 | ||
| 4 | 2 | Standard width | 5m/10m/15m/20m | 1PLY | 34.56 | 7.08 | ||
| 5 | 3 | Standard width | 5m/10m/15m/20m | 1PLY | 53.76 | 11.01 | ||
| 6 | 4 | Standard width | 5m/10m/15m/20m | 1PLY | 72.96 | 14.94 | ||
| 7 | 5 | Standard width | 5m/10m/15m/20m | 2PLY | 92.16 | 18.87 | ||
| 8 | 6 | Standard width | 5m/10m/15m/20m | 3PLY | 111.36 | 22.81 | ||
| 9 | 8 | Standard width | 5m/10m/15m/20m | 4PLY | 149.76 | 30.67 | ||
| 10 | 10 | Standard width | 5m/10m/15m/20m | 5PLY | 188.16 | 38.54 | ||
| 11 | 12 | Standard width | 5m/10m/15m/20m | 8PLY | 226.56 | 46.40 | ||
| 12 | 15 | Standard width | 5m/10m/15m/20m | 10PLY | 284.16 | 58.20 | ||
| 13 | 20 | Standard width | 5m/10m/15m/20m | ≥10PLY | 64.00 | 13.11 | ||
| 14 | 25 | Standard width | 5m/10m/15m/20m | ≥10PLY | 80.00 | 16.38 | ||
| 15 | 30 | Standard width | 5m/10m/15m/20m | ≥10PLY | 96.00 | 19.66 | ||
| 16 | 50 | Standard width | 5m/10m/15m/20m | ≥10PLY | 160.00 | 32.77 | ||
Tabulated weight values are provided for informational purposes only. As dimensional specifications of rubber sheets are fully customizable per project requirements, actual weights may vary accordingly. For precise weight calculations tailored to your application, please submit specific technical parameters to our engineering team.
Insertion materials:
 |
 |
 |
 |
| Nylon canvas | Mesh fabric | Nylon mesh fabric | Encrypted canvas |
EPDM solid rubber roll material application
- Diaphragm sheeting applications, Fluid Transfer applications, Control valves, Interior and exterior environments.
- Fluid Transfer applications
- Gas & fluid meter equipment
- Control valves
- Regulators
- Interior & exterior environments
