70+/5 Hardness black industrial wear-resistant rubber sheet
Reference Standard: ASTM standard
Quality Certification: SGS RoHS2.0 REACH
Thickness: 3mm; Thickness over 15mm, available in sheet form
Specification (W/L):
Width: Standard 1mtrs 1.2mtrs 1.4mtrs 1.5mtrs 1.6mtrs 1.8mtrs 2.0mtrs
Length: Standard 5mtrs 10mtrs 15mtrs 20mtrs. Available upon request
Color: Black
Packing Information: Regular / Up to your choice
Packed with plastic film.
Packed with plastic film and with PP woven bag.
Wooden pallet.
According to the customer request, fixed-length or heavy package.
Product Supply Form: Roll / Sheet or Plate / Strip
Get more information:
Email: info@chn-rubber.com
P .H & Wechat: 008615222735180
For demanding applications requiring a reliable and versatile rubber material, look no further than our premium china sbr rubber sheet. Sourced and manufactured to the highest standards in China, this SBR rubber sheet delivers exceptional performance across a broad spectrum of industries. Our china sbr rubber sheet is specifically formulated to provide an optimal balance of properties. Its specific gravity of 1.6 ensures a consistent material density, while the hardness of 70+/-5 Shore A offers excellent flexibility combined with good resistance to wear and tear. This makes it an ideal choice for environments requiring both durability and adaptability.
KEY FEATURES
- Manufactured in China: Benefit from competitive pricing and reliable sourcing.
- Hardness 70+/-5 Shore A: Excellent balance of flexibility and durability.
- Good Abrasion Resistance: Withstands wear and tear in demanding applications.
- Resilient and Flexible: Adapts to various shapes and movements.
- Water Resistant: Suitable for environments with moisture exposure.
- Versatile Applications: Ideal for gaskets, seals, matting, vibration dampening, and more.
SBR RUBBER SHEET PERFORMANCE & SPECIFICATION
| SBR RUBBER SHEET TECHNICAL PARAMETERS | ||||||||
| Code | Specific Gravity | Hardness (+/-5) | Tensile Strength | Elongation at break | Colour | Finish Type | ||
| g/cm³ | Shore A | Mpa | (min） % | |||||
| STANSDARD | ASTM D397 | ASTM D2240 | ASTM D412 | ASTM D412 | --- | --- | ||
| ZXZRS20101S | 1.6+/-0.05 | 70 | 2.5-3 | 180 | Black | Smooth in both sides OR 1/2 With sides cloth OR 1 side With anti-slip texture | ||
| ZXZRS20201S | 1.6+/-0.05 | 70 | 2.5-3 | 180 | Red | |||
| ZXZRS20401S | 1.6+/-0.05 | 70 | 2.5-3 | 180 | Green | |||
| ZXZRS20001S | 1.6+/-0.05 | 70 | 2.5-3 | 180 | customized production according to demand | |||
| Note:1MPa =10.2 Kg/cm² 1N/mm =1.02 Kg/cm | ||||||||
| SPECIFICATION | ||||||||
| Item | Thickness | Width | Length | Insertion | Weight | |||
| mm | m | m | Material | Layers | KGS/m² | LB/ft² | ||
| 1 | 1 | Standard width | 5m/10m/15m/20m | Nylon canvas / Mesh fabric / Nylon mesh fabric / Encrypted canvas | / | 15.36 | 3.15 | |
| 2 | 1.5 | Standard width | 5m/10m/15m/20m | / | 24.96 | 5.11 | ||
| 3 | 1.7 | Standard width | 5m/10m/15m/20m | 1PLY | 28.80 | 5.90 | ||
| 4 | 2 | Standard width | 5m/10m/15m/20m | 1PLY | 34.56 | 7.08 | ||
| 5 | 3 | Standard width | 5m/10m/15m/20m | 1PLY | 53.76 | 11.01 | ||
| 6 | 4 | Standard width | 5m/10m/15m/20m | 1PLY | 72.96 | 14.94 | ||
| 7 | 5 | Standard width | 5m/10m/15m/20m | 2PLY | 92.16 | 18.87 | ||
| 8 | 6 | Standard width | 5m/10m/15m/20m | 3PLY | 111.36 | 22.81 | ||
| 9 | 8 | Standard width | 5m/10m/15m/20m | 4PLY | 149.76 | 30.67 | ||
| 10 | 10 | Standard width | 5m/10m/15m/20m | 5PLY | 188.16 | 38.54 | ||
| 11 | 12 | Standard width | 5m/10m/15m/20m | 8PLY | 226.56 | 46.40 | ||
| 12 | 15 | Standard width | 5m/10m/15m/20m | 10PLY | 284.16 | 58.20 | ||
| 13 | 20 | Standard width | 5m/10m/15m/20m | ≥10PLY | 64.00 | 13.11 | ||
| 14 | 25 | Standard width | 5m/10m/15m/20m | ≥10PLY | 80.00 | 16.38 | ||
| 15 | 30 | Standard width | 5m/10m/15m/20m | ≥10PLY | 96.00 | 19.66 | ||
| 16 | 50 | Standard width | 5m/10m/15m/20m | ≥10PLY | 160.00 | 32.77 | ||
* Tabulated weight values are provided for informational purposes only. As dimensional specifications of rubber sheets are fully customizable per project requirements, actual weights may vary accordingly. For precise weight calculations tailored to your application, please submit specific technical parameters to our engineering team.
* Please ensure the product meets your application specification prior to order placement.
Insertion materials:
 |
 |
 |
 |
| Nylon canvas | Mesh fabric | Nylon mesh fabric | Encrypted canvas |
TARGET APPLICATIONS
- 1. Industrial Gaskets and Seals: Create reliable seals in machinery and equipment.
- 2. Commercial Flooring and Matting: Provide durable and comfortable surfaces.
- 3. Automotive Components: Use in vibration dampening and sealing applications.
- 4. Construction and Building: Employ for expansion joints and protective layers.
- 5. General Purpose Rubber Parts: Fabricate custom rubber components for various needs.
When you choose our china sbr rubber sheet, you are selecting a material that is both cost-effective and performance-driven. We are committed to providing high-quality china sbr rubber sheet solutions to meet your specific requirements. Request a detailed specification sheet and discuss your project needs with our expert team today to discover how our china sbr rubber sheet can benefit your business.
